Embedded power distribution box depth diagram
Embedded power distribution boxes typically feature a wall-embedded flange, internal mounting plate, and a depth ranging from 150mm to 300mm depending on the model and voltage rating.
Structural Overview
Embedded power distribution boxes are designed to be installed within walls, with the flange positioned on the internal side of the enclosure and no external wall-mounting slot . The enclosure is usually made of cold-rolled or stainless steel with a thickness of 1.5–3mm, providing mechanical rigidity and protection against environmental factors . Doors are hinged and can open up to 90° internally, allowing access to the internal components.
Depth and Mounting
- Typical Depth: 150–300mm for low-voltage embedded units, depending on the number of circuit breakers and internal components .
- Internal Mounting Plate: Components such as circuit breakers, relays, and sensors are mounted vertically on a removable backplate or DIN rail system .
- Flange and Wall Integration: The flange is recessed inside the wall, ensuring a flush finish with the wall surface. The enclosure depth must accommodate both the internal components and the wiring space behind the mounting plate .
Internal Layout
- Circuit Breakers and Relays: Arranged vertically for easy access and maintenance.
- Schematic Pocket: Many designs include an integrated diagram holder on the inside of the door for wiring schematics and maintenance documentation .
- Wiring Space: Sufficient clearance is provided behind the mounting plate to route cables safely and maintain IP protection ratings.
Additional Considerations
- IP Rating: Embedded boxes often achieve IP30–IP67, depending on sealing and gasket design .
- Material and Coating: Epoxy powder coating or electrostatic coating ensures corrosion resistance and durability .
- Installation Environment: Suitable for indoor or outdoor use, with temperature and humidity tolerances specified by the manufacturer . For precise depth diagrams, CAD files or manufacturer datasheets (such as ABB MNS low-voltage cabinets or custom smart distribution boards) provide exact dimensions, mounting slots, and internal component placement . These resources are essential for engineers planning wall-embedded installations.
