Classification and Standards of Relay Protection

Relay protection in power systems is standardized through IEEE, ANSI, NEMA, and ISO codes, which classify relays by function, operating characteristics, and application.

IEEE and ANSI Standards

IEEE Standards are widely used for relay protection and provide detailed guidance on design, testing, and application of relays. Key standards include:

• IEEE C37.2: Defines device function numbers and symbols for protective relays, enabling consistent identification and documentation of relay functions in power systems .
• IEEE C37.90: Specifies service conditions, electrical and thermal ratings, and testing requirements for relays and relay systems, ensuring reliability and reproducibility .
• IEEE C37.111: Covers digital and multifunctional relays, including performance criteria and communication protocols . ANSI Codes are often integrated with IEEE standards to classify relays by function. Common ANSI device numbers include:
• 50/51: Instantaneous and time-delayed overcurrent protection
• 49: Thermal overload protection
• 27: Undervoltage protection
• 59: Overvoltage protection
• 25: Synchronism-check relay
• 46: Phase-balance or negative-sequence protection
• 50N/51N: Ground fault protection
• 32: Directional power relay
• 47: Phase-sequence or phase-loss protection

NEMA Standards

The National Electrical Manufacturers Association (NEMA) provides additional guidelines for protective relays:

• NEMA SG-4: Covers general specifications for protective relays
• NEMA TR 1: Provides testing and performance recommendations for relay systems These standards ensure that relays meet operational, environmental, and safety requirements.

ISO Standards

Internationally, ISO standards provide a framework for relay protection in industrial and power systems:

• ISO 8528: Relates to generator sets and protection
• ISO 13849: Safety-related control systems
• ISO 61850: Communication networks and systems for power utility automation, including relay integration

Classification by Function and Operating Principle

Relays are also classified based on operating parameters and logic:

• By operating parameter: Current, voltage, impedance, power, frequency
• By operating characteristic: Definite time, inverse time, stepped, or logic-based (differential, overfluxing)
• By application: Differential, directional, distance, restricted, or multifunctional relays

Practical Considerations

Standards ensure that relays:

• Operate reliably and selectively to isolate faults
• Coordinate with other protective devices for system stability
• Meet testing, environmental, and electromagnetic compatibility requirements
• Provide clear documentation for settings, functions, and interconnections Using these standards, engineers can design, implement, and maintain relay protection systems that are safe, efficient, and interoperable across different power system components.
